Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 135
plan and elevationis determined as previously explained (Article93). In projecting the points from the plan tothe elevation onto the edges B and D, it is diffi-cult to determine the exact V projections, owingto the steep slope of B and D. The position of 112 MECHAXICAL DRAFTING the points in… … Fig. 75. Intersection of Circular Cylinder with an IrregularFour-Sided Prism. 97. Intersection of a Cylinder with a Prism. Fig. 75 represents the intersection of a circularcylinder and an irregular four-sided prism.The two are placed in the first angle, the prism
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
