Mechanics of engineering. Comprising statics and dynamics of solids: and the mechanics of the materials of constructions, or strength and elasticity of beams, columns, arches, shafts, etc (1888)
Church, Irving P[orter], 1851- [from old catalog] · New York, J. Wiley & sons · leaf 432
ICS. 419 Draw a vertical through p. The H of the required equili-brium polygon must satisfy the proportion H: Hx : : rs :pm. (See § 338). Hence construct or compute H fromthe proportion and draw a vertical at distance H fromthe load-line (on the left of the load-line here); its inter-section with n… … 342. Symmetrical Case of the Foregoing Problem.—If twopoints A and B are on a level, the third, p, on the middlevertical between them ; and the loads (an even number)symmetrically disposed both in position and magnitude, aboutp, we may proceed more simply, as follows: (Fig. 372). From symmetry…
Mechanics, Applied · Engineering · Strength of materials
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
