Mechanics of engineering. Comprising statics and dynamics of solids: and the mechanics of the materials of constructions, or strength and elasticity of beams, columns, arches, shafts, etc (1888)
Church, Irving P[orter], 1851- [from old catalog] · New York, J. Wiley & sons · leaf 454
ight be 200 lbs. to theinch, say, and that of the space-diagram (on the left) 30 ft.to the inch. The cross section m lies in a portion TK, of the rib, cor-responding to the rod or segment be of the equilibriumpolygon; hence its anti-stress-resultant is a force R2 actingin the line be, and of an… … Fig. 405. Fio. 406. taking the tangent line and the normal at m as axes weshould have I (tang, comps.) = 0 ; I (norm, comps.) = 0 \and 2 (moms, about gravity axis of the section at m) = 0,and could thus find the unknowns plf p2, and J, which ap-pear in the expressions pYF the thrust, &: the…
Mechanics, Applied · Engineering · Strength of materials
