Hydraulic motors, with related subjects, including centrifugal pumps, pipes, and open channels, designed as a text-book for engineering schools (1905)
Church, Irving Porter, 1851-1931 · New York : J. Wiley & Sons; [etc, ] · leaf 176
gh heads, say above 300 or 400 ft.: Pelton wheel;or radial outward-flow, segmental-feed, free-deviation turbine(i.e., a Girard impulse wheel); or a combination of both, onhorizontal shaft and cast- or wrought-iron case; often withdraft-tube. 89. General Theory of Reaction Turbines.—The theory ofthe… … 1^ Fig. 75. mixed-flow turbine having its shaft, £, vertical. The entrance-point, 1, is describing a horizontal circle A . . . 1 . . . M witha velocity, vx, of proper value for best effect, the correspondingvelocity of the exit-point N being vn, in horizontal circleT . . . N.. . (x, this circle…
