Mechanics of the household; a course of study devoted to domestic machinery and household mechanical appliances (1918)
Keene, E. S. (Edward Spencer), b. 1864 · New York, McGraw-Hill book company, inc.; · leaf 111
Fig. 87.—Bath tub with shower. 100 MECHANICS OF THE HOUSEHOLD and close by the same sort of mechanism as is shown in Fig. 71,a description of which appears on page 90. The overflow is shown in detail in Fig. 89. The part A appearsinside the tub. It is made water-tight around the edge C by a … Fig. 88.—Double Fuller cock for bath tubs. rubber washer that is clamped tight to the surfaces by the nutJS. In case of leakage, the overflow may be removed for repairby unscrewing the union attached to the piece D and removingthe nut B.
