Mechanics of the household; a course of study devoted to domestic machinery and household mechanical appliances (1918)
Keene, E. S. (Edward Spencer), b. 1864 · New York, McGraw-Hill book company, inc.; · leaf 113
nd. Theparts C and E are unions that permit the pipe or bowl to beremoved without disturbing the remainder of the plumbing.From the form of the trap it will be seen that the U-shaped partbelow the dotted line F will always remain full of water and soprevents the escape of air from the sewer. In… … Fig. 94.—Corner wash basin. PLUMBING 103 The traps used in Figs. 90 and 92 are the same in principle asFig. 95 but are made to discharge into a pipe placed in the wall in-stead of under the floor. The trap in Fig. 94 is a form knownas the bottle-trap that is sometimes used in the more…
Heating · Lighting · Plumbing
