Mechanics of the household; a course of study devoted to domestic machinery and household mechanical appliances (1918)
Keene, E. S. (Edward Spencer), b. 1864 · New York, McGraw-Hill book company, inc.; · leaf 178
1 Air Chamber Nut 2 Brass Tube for AirChamber 3 Air Chamber 4 Brass Cock 5 Cap Screw 6 Leather Washer 7 Handle Pin 8 Pitman 9 Handle 10 Brass CoveredPiston Rod 11 Fulcrum 12 Fulcrum Pin 13 Brass Stu.ffijig ifut … 14 Cap 15 Fulcrum Ring 16 Fulcrum RingPin 17 Plunger 18 Cylinder 19 Cap Screw 20 Lower Valve 21 Brass ValveSeat 22 Base 123 Bottom Brass Ferrule24 Bottom Nut Fig. 150.—The terms by which the parts of a force pump are designated. the waste water is discharged to the sewer by the waste pipe onthe…
Heating · Lighting · Plumbing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
