Maurer, Edward R. (Edward Rose), b. 1869 · New York : John Wiley & sons, inc.; [etc., etc.] · leaf 148
^ cos 9. (6) Now compare (i) and (4), (2) and (5), and(3) and (6) and note that the formulas forthe motion of C contain an extra term.Each of these terms depends on c (= r/l),or on the obliquity of the connectingrod (maximum inclination of the rod to theline of stroke OC). The smaller c (thelonger… … Fig. 245 138 Chap, vii Fig. 245 presents a comparison of the motion of the crosshead C and themotion of Q. The solid lines refer to the first motion and the dashed lines tothe second. Vc is the velocity-distance {v-s) graph and Ac is the acceleration-distance (as) graph for the motion of C. Vq is…
Mechanics
