Medieval architecture, its origins and development, with lists of monuments and bibliographies (1912)
Porter, Arthur Kingsley, 1883-1933 · New Haven, Yale University Press · leaf 100
imagined. Even greater difficulties were caused by the constructionof the wall ribs. Supposing the diagonals and transverse ribsin place, let us proceed to the construction of the wall arch, ab, The most notable instance is at St. Martin dEtanipes, c. 1160. But here the four-sidedcompartments are… … III. IM. — Plan of Morieiival RIB VAULTS ON A CURVED PLAN and the arch of the main arcade, dc. It is evident that thethree arches ad, ah, dc, and ac all have bases of varying length.Consequently, if they were constructed with a semicircularradius, they would all rise to the varying heights shown in…
Architecture, Medieval · Architecture
Internet Archive · University of Connecticut Library · Public Domain Mark 1.0. Free to use for anything.
