Medieval architecture, its origins and development, with lists of monuments and bibliographies (1909)

Porter, Arthur Kingsley, 1883-1933 · New York, The Baker and Taylor Company · leaf 53

An illustration from Medieval architecture, its origins and development, with lists of monuments and bibliographies, 1909, leaf 53 — ge vault, say one hundred feet long, asit would require a centering also one hundred feet long. The 15 THE HERITAGE OF ANTIQUITY thrifty Romans accordingly devised the scheme shown in 111. 8and 111. 7, Fig. 5. iVlong the space to be vaulted, at convenientintervals, arches — called ribs — were… … III. la. — Perspective of the Barrel Vault intermediate arches were sprung, covering the space betweenthe original arches, on whose edges they rested. If the introduction of the principle of the arch was an ad-vance of grave significance, the vault which followed as a neces-sary corollary was…

Architecture, Medieval

Internet Archive · Wellesley College Library · Public Domain Mark 1.0. Free to use for anything.
