by the chisel. FILES, FILING, AND SCRAPING 89 If possible, the handicraft instructor should obtain all shapesand cuts of files for purposes of observation by students,and also at least one set showing the various processes ofmanufacture. Filing.—The position of the work is most important infiling,… … Fia. 30. To hold the file, only one method is adopted for the righthand, and by referring to Fig. 30 it will be observed that theend of the handle is allowed to rest in the palm of the hand,and the fingers close round it, with the index-finger upon thetop or along the side of the handle. Three…
