Metal-work; a handbook for teachers and students (1914)
Adam, Hugh M. [from old catalog], Evans, James Humphrey, [from old catalog] joint author · New York, Longmans, Green and co.; London, E. Arnold · leaf 197
where required tosuit the length of the work by means of a nut and screw. Fig. 163 shows a vertical section through the fast head-stock of a plain lathe. It will be noted that the front of themandril runs in a conical bearing, the journal on the mandrilbeing cut to fit the bearing. The back-end is… … Fig. 163. The great advantage of this type of bearing is that it is possibleto make all adjustments for wear in the bearing parts without
Metal-work
