Metal-work; a handbook for teachers and students (1914)
Adam, Hugh M. [from old catalog], Evans, James Humphrey, [from old catalog] joint author · New York, Longmans, Green and co.; London, E. Arnold · leaf 206
Fig. 173. LATHES AND LATHE WORK 189 to binding the barrel, also acts as a key to prevent its revolving.Figs. 174 and 175 show the complete fast and loose head-stocks of the screw-cutting lathe. The slide rest of the screw- … FiG. 174. cutting lathe is much more complicated than the type usedin the plain lathe, as some arrangement must be made wherebyit can be locked to the lead-screw. This is effected by carry-ing the bottom-slideover the bed, to whichit is fitted in the usualway by chipping strips.The parts resting…
Metal-work
