Metal-work; a handbook for teachers and students (1914)

Adam, Hugh M. [from old catalog], Evans, James Humphrey, [from old catalog] joint author · New York, Longmans, Green and co.; London, E. Arnold · leaf 341

An illustration from Metal-work; a handbook for teachers and students, 1914, leaf 341
end view looking in the direction of the arrow K to a scale of half full size ; and {d) draw, separatelyfrom the rest of the drawing, a section of the bevelwheels in gear, to a scale of full size, the section to betaken at the line AB. (40.) or- Design and draw the lamp bracket shown in Fig. G to… … 4screwNwt Fig. 6. EXAMINATION PAPERS 325 WEITTEN EXAMINATION (Four Hours). Part I. Not more than four questions to be attempted in Part I. 1. Metal-work of a mere elementary character, involving onlya few simple tools and much, lighter metals, is being advised asmore suitable for boys of twelve to…

Metal-work

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
