any. The work table is arranged similarly to that of aknee-type milling machine with the addition that it has fittedto the work table, in such positions as to read in two directionsat right angles from one another, two finely graduated scaleswhich are provided with verniers. With this construction… … 212 METHODS OF MACHINE SHOP WORK work may be begun with the first reading at the zero or, morefrequently, at an even inch of the scale. To prevent the side-wise crawling tendency of the drill on the surface of the work,it is guided by a bush inserted in an arm which projects from themachine frame…
