, the blank piece of work is secured to the work table andalongside of it a model or former, shaped to the exact outlineof the desired piece. At each side of the cutter spindle, at itslower end, is a clamp socket. In one or the other of these,according to convenience, a pin of the exact diameter of… … 244 METHODS OF MACHINE SHOP WORK ing its profile exactly, the result being to reproduce the sameprofile in the piece of work. THE CAM-CUTTING MACHINE Another important modification of the milling machine isfound in the cam-cutting machine of which an example, by theGarvin ]\lachine Company, is…
