The microscope; an introduction to microscopic methods and to histology (1901)
Gage, Simon Henry, 1851-1944 · Ithaca, N.Y. Comstock publishing company · leaf 22
). Fig. 21. Diagram showing theprinciple of a compound microscope withthe course of the rays from the object(A B) through the objective to the realimage (B A), thence through the ocu-lar a?id into the eye to the retinal image{A-B2), and the projection of the retinalimage into the field of vision as… … i- :$a* IO MICROSCOPE AND ACCESSORIES \_CH.I Axis. The principal optic axis of the microscope and of the eye. Cr. Cornea of the eye. L. Crystalline lens of the eye. R. Single, ideal, re-fracting surface at which all the refractions of the eye may be assumed to takeplace. F. F. The principal focus…
Microscopy
