23). Fig. 21. Diagram shozuing the prin-ciple of a compound microscope withthe course of the rays from the object(A B) through the objective to the real-image {£ A), thence through the ocu-lar and into the eye to the retinal image{A1 B1), and the projection of the retinalimage into the field of… … CH. /.] MICROSCOPE AND ACCESSORIES. II Axis. The principal optic axis of the microscope and of the eye. Cr. Cornea of the eye. L. Crystalline lens of the eye. R. Single, ideal, re-fracting surface at which all the refractions of the eye may be assumed to takeplace. F.E. The principal focus of the…
Microscopy
