The microscope : an introduction to microscopic methods and to histology (1911)

Gage, Simon Henry, 1851-1944 · Ithaca, N.Y. : Comstock Pub. Co. · leaf 32

An illustration from The microscope : an introduction to microscopic methods and to histology, 1911, leaf 32 — axis of the ob-jective. B C. Back Combination, composed of aplano-concave lens of flint glass (E), and adouble convex lens of crown glass {c).E C. Front Combination.C, 0, si. The cover-glass, object and slide.Mirror. The mirror is represented as abovethe stage, and as reflecting parallel rays… … 12 MICROSCOPE AND ACCESSORIES. \CH. I. \ 16. Immersion Objectives. — An immersion objective is one with which thereis some liquid placed between the front of the objective and the object or cover-glass. The most common immersion objectives are those (A) in which water isused as the immersion fluid,…

Microscopy

Internet Archive · Biodiversity Heritage Library · Public Domain Mark 1.0. Free to use for anything.
