The microscope; an introduction to microscopic methods and to histology (1917)
Gage, Simon Henry, 1851-1944 · [Ithaca, N.Y.] The Comstock Pub. Co. · leaf 201
flect the light directlydownward. Image The picture of the microscopic objectreflected down upon the drawing paper. Sh Opaque shield to screen the light from thedrawing surface. 188 DRAWINGS FOR PUBLICATION [Ch. VI of every writer the possibility of appealing to the eye by means ofpictures and… … Fig. 114. The Microscope Arranged for Drawing on a Horizontal Surface. (From Optic Projection). The microscope is of the handle type (H) with the fine adjustment (/ a) on theside below the coarse adjustment (c a). The ocular is of the Huygenian form with the real image at (r i). Prism, the…
Microscopy · Microscopy -- Technique
Internet Archive · Biodiversity Heritage Library · Public Domain Mark 1.0. Free to use for anything.
