be formed. cl Center of the lens. 1 This shows that the object is 1 unit long and its distance from the center ofthe lens is also 1. 1234 The image is 4 units distant from the center of the lens, and the imageis consequently 4 units long. 306 MAGNIFICATION OF OBJECTIVES AND OCULARS [Ch. IX scope or… … AK- Fig. 182. Projected Virtual Image of a Magnifier.(Simple Microscope or Ocular). The projection distance is 250 mm. from the nodal point in the crystalline lensof the eye. Axis The optic axis of the magnifier and of the eye. A1 B1 The object of the simple microscope or real image of the…
