The microscope : its construction and management : including technique, photo-micrography, and the past and future of the microscope (1893)

Heurck, Henri van, 1838-1909 · London : C. Lockwood ; New York : D. Van Nostrand Co. · leaf 357

An illustration from The microscope : its construction and management : including technique, photo-micrography, and the past and future of the microscope, 1893, leaf 357 — Fig, 204. Fig. 205. To make these tools it is first necessary to have what is termed agauge. This is made by cutting out of a plate of brass or steel acurve, depending on radius required. The tool is then shaped byturning it on an ordinary lathe until its surface accurately coincideswith the curve…

Microscopy

Internet Archive · Medical Heritage Library · Public Domain Mark 1.0. Free to use for anything.
