then the prism carrierV is separated from the bodyZ, and lastly, the latter ispressed on to the tube A, andin this manner the instrumentbecomes a vertical one. The piece A P is adjustedon the stem D by means of a moveable pin, having a knob g. Thepiece V, which enters the tube A by slightly… … 356 THE MICROSCOPE IN THE PAST AND IN THE FUTURE. The mirror H moves round in a circle so as to admit of obliqueillumination. The stage is moved by the pinion O. The adjustingscrew Q produces the slow movement. The variable diaphragm R isfixed on a piece fitted with a hinge and pivot, so that it…
