or the left part of the objective. The manner in which the delineating pencils are transmittedthrough the system may be such as to require crossing over of therays from the right-hand half of the objective to the left eye-piece,and vice versa. But it is not essential to binocular effect. In… … Fig. 71 BINOCULAR MICROSCOPES 97 in the same plane, it will be necessary for the rays to cross ; but ifthey have been reflected an odd number of times, it is not only un-necessary, but is destructive of orthoscopic effect, provided ordinary-eye-pieces (non- erecting) are employed. Hence in the…
