The microscopy of vegetable foods, with special reference to the detection of adulteration and the diagnosis of mixtures (1916)
Winton, Andrew Lincoln, 1864-1946, Moeller, Josef, 1848-1924, Winton, Kate Grace Barber, 1882- · New York, John Wiley & sons, inc.; [etc., etc.] · leaf 111
od-erate thickness; but further inwardthe cells are smaller, thicker walledand are longitudinally much elongated.The fibro-vascular bundles run amongthese elongated cells and parallel tothem. 3. Parenchyma (p). Toward theinner surface the cell-walls diminish inthickness and the sclerenchyma… … Fig. 62. Maize. Longitudinal sectionof fruit. e pericarp; n remains ofstigma; fs base of kernel; eg hornyendosperm; eiu floury endosperm; scand ss scutellum of embryo; e epithe-lium of scutellum; k plumule; w (be-low) primary root; iis root sheath;IV (above) secondary root; st stem,X6. (Sachs.)…
Plant anatomy · Food adulteration and inspection · Microscopy
