The model architect : a series of original designs for cottages, villas, suburban residences, etc., accompanied by explanations, specifications, estimates, and elaborate details : prepared expressly for the use of projectors and artisans throughout the United States (1852)

Sloan, Samuel, 1815-1884 · Philadelphia : E.S. Jones & Co. · leaf 206

An illustration from The model architect : a series of original designs for cottages, villas, suburban residences, etc., accompanied by explanations, specifications, estimates, and elaborate details : prepared expressly for the use of projectors and artisans throughout the United States, 1852, leaf 206
AN ORIENTAL VILLA The building details are represented on Plates LXVII. and LXVIII. Figure 1 is a front view of the windows over theverandahs drawn to the scale of half an inch to the foot. Fig. 2 is a sectional view of the same. The ornaments shouldbe either of wood or iron. The windows of the…

Architecture, Domestic · Country homes
