Model making; including workshop practice, design and construction of models, a practical treatise for the amateur and professional mechanic .. (1919)

Yates, Raymond F. (Raymond Francis), 1895- ed · New York, The Norman W. Henley Pub. Co. · leaf 148

An illustration from Model making; including workshop practice, design and construction of models, a practical treatise for the amateur and professional mechanic .., 1919, leaf 148 — 3-48 T/qP, … Fig. 102B—Details of the twin-cylinder engine 146 Model Engineering Crankshaft.—This can be made out of a solid piece,but the designer of this engine has had some experiencewith built-up crankshafts and can heartily recommendthem. In fact, he prefers them, knowing of one instancewhere a built-up…
