Model making; including workshop practice, design and construction of models, a practical treatise for the amateur and professional mechanic .. (1919)
Yates, Raymond F. (Raymond Francis), 1895- ed · New York, The Norman W. Henley Pub. Co. · leaf 203
ving shaft. The shaft of the turbine wheel is made as long aspossible, and the outer end supported in an outboardbearing. Each bearing is fitted with an oil ring and res-ervoir. Where the shaft passes through the casing, astuffing box and gland is introduced. As the pressure atthis point is only… … u Q A Model Steam Turbine 201 carefully constructed, and when completed, the wheelshould be in perfect balance. The design requires fortyvanes or buckets arranged around the circumference ofthe wheel. Fig. 140 show^s in detail the construction of thewheel. This wheel is made with a solid web…
