Model making; including workshop practice, design and construction of models, a practical treatise for the amateur and professional mechanic .. (1919)

Yates, Raymond F. (Raymond Francis), 1895- ed · New York, The Norman W. Henley Pub. Co. · leaf 277

An illustration from Model making; including workshop practice, design and construction of models, a practical treatise for the amateur and professional mechanic .., 1919, leaf 277 — Fig. 185—The submarine chaser complete placed well forward. The propeller shaft housing issecurely held in its proper relation to the hull by meansof brackets formed by bending annealed brass strip tothe proper shape and afterward filing it thin and smooth.One bracket, the inside one, is soldered… … A Model Submarine Chaser 275 Avhere the power is transmitted from motor to propellershaft. The coupling is the simple type comprising asliort length of coiled brass spring. The outside bracketnmst, obviously, be left unsoldered in order that theshaft tube may be inserted through the hull. The motor…

Machinery

Internet Archive · Public Domain Mark 1.0. Free to use for anything.
