Model making; including workshop practice, design and construction of models, a practical treatise for the amateur and professional mechanic .. (1919)

Yates, Raymond F. (Raymond Francis), 1895- ed · New York, The Norman W. Henley Pub. Co. · leaf 336

An illustration from Model making; including workshop practice, design and construction of models, a practical treatise for the amateur and professional mechanic .., 1919, leaf 336 — Eight, the number of collars required, 6-32 x Sc-inch round head brass screws will be required for thesecollars. An Electric Double-Drum Hoist 333 The base angles (F), Fig. 268, are merely strips ofmetal shaped as indicated. Their purpose is to hold theframe of the hoist to the base. Four are…
