d a short dis-tance apart. If desired, the nails can be of such a lengththat they will protrude a short distance on the oppositesides of the blocks so the tractors will obtain a bettergrip on the surface the tank is traveling on. The driving units will now be considered. The driv-ing rods are… … Fig. 296—The rear of the tank with the cover removed to show themounting of the driving motors by the one-inch wooden strip that runs from the motorsto the crosspiece on the back of the tank. In order tosteer the tank and to avoid complications in the drivingmechanism, two separate motors are used;…
