Steam engines, a thorough and practical presentation of modern steam engine practice (1920)
Ludy, Llewellyn V., 1875-, American Technical Society · Chicago, American technical society · leaf 24
of a good grade ofcast iron and is usually heavily ribbed and made high enough topermit the wheels to clear the floor. The sub-base is often omittedwith engines of large size, the engine being set upon a concrete base. Frame. The frame 2 is the element or link by which all of theparts of the engine… … Fig. 5. Plan View of Modern Simple Engine that it is strong enough to take all the stresses put upon it. Thetype, size, and details of the frame vary with the type and size of
Steam-engines
