Model making; including workshop practice, design and construction of models, a practical treatise for the amateur and professional mechanic .. (1919)
Yates, Raymond F. (Raymond Francis), 1895- ed · New York, The Norman W. Henley Pub. Co. · leaf 65
t limited, though sufficient formodel making. The cabinet is made of cedar, % i^^ch thick, the boardshaving been secured by tearing apart an old cedar chestthat had been discarded. This made it possible to pro- 62 Model Engineering vide an exterior shellac finish that presents a good ap-pearance… … Fig. 37—The lathe cabinet open, ready for work appearance. Brass dowel pins are used to hold the endsof the cabinet in perfect alignment with the top when itis closed. These are not shown on the drawing. Ironbrackets are nsed to stiffen the back. It will be founddesirable to provide four small…
