ed fromin. the illustration, but this is due to the perspective, thetube box having been placed at the same angle as the trac-ing paper. In the illustration the physician has one handon a handle which regulates the size of the opening in thediaphragm plate. Near this are other handles, whose usehas… … NOTE 168 —FIGURE i — AN X-LIGHT TUBE FORTREATING TWO PATIENTS. THE CATHODESTREAMS ARE REPRESENTED BY THEDOTTED LINES; X-LIGHT BY THE DOTTEDCROSSED LINES. TB, NON-RADIABLE TUBEBOX. CC, CATHODES. CT, NON-RADIABLECONES ATTACHED TO THE TUBE BOX Plate 123
