Modern American locomotive engines; their design, construction and management. A practical work for practical men (1883)
Edwards, Emory, b. 1841 · Bridgeport, Conn., Frederick Keppy · leaf 210
Fig. 63. Fig. 62. 200 LOCOMOTIVE ENGINES. link is curved to the radius of the radius hnk //, andthe radius Hnk block G, slides in the curved groove ofthe link, moving from G to G, as the radius link ismoved from H to H. The reversing link Alls pivoted at one end,^, to theradius link H, and at its…
Locomotives
