Modern cabinetwork, furniture & fitments; an account of the theory & practice in the production of all kinds of cabinetwork & furniture, with chapters on the growth and progress of design and construction; (1910)

Wells, Percy A, Hooper, John · London, B.T. Batsford; New York, Jone Lane company · leaf 355

An illustration from Modern cabinetwork, furniture & fitments; an account of the theory & practice in the production of all kinds of cabinetwork & furniture, with chapters on the growth and progress of design and construction;, 1910, leaf 355
en thedoor shuts on to the carcase end and when the cut-ting in is equalised. In this case the door wouldswing round clear of the end. Fig. 4 is the planof a centre hinge showing a method of findingthe centre. Divide the thickness of the stile intothree as seen in the dotted lines. From thecorner… … 4- V/////////AtiWjjjjJJvJj Method of Finding Centre andFixing Centre Hinge.

Cabinetwork · Furniture

Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
