Modern cabinet work, furniture & fitments; an account of the theory & practice in the production of all kinds of cabinet work & furniture with chapters on the growth and progress of design and construction; illustrated by over 1000 practical workshop drawings, photographs & original designs (1922)
Wells, Percy A, Hooper, John, b. 1882 · Philadelphia, J.B. Lippincott Company · leaf 359
en thedoor shuts on to the carcase end and when the cut-ting in is equalised. In this case the door wouldswing round clear of the end. Fig. 4 is the planof a centre hinge showing a method of findingthe centre. Divide the thickness of the stile intothree as seen in the dotted lines. From thecorner… … 4- Method of Finding Centre andFixing Centre Hinge.
Cabinetwork · Furniture making
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
