that the studentmust imagine the wall as lying flat on the paper, and the floor below the groundline, or as it is technically known, the X Y line. This the student can easily illus-trate for himself by folding the paper up to form a right angle, and holding a note-book at one end, when the three… … Plan and Elevation of a Semi-circular Table. 32 MODERN CABINETWORK, FURNITURE, AND FITMENTS. These views are essential if the correct shape of a job is to be known, e.g., of a semicircular or elliptic table, see p. 31. The elevations are straight while the plans give the real shape, as in f. 1…
