Modern carpentry and joinery : being a compilation of the very best things and most modern and practical methods known in the arts of carpentry and joinery (1910)
Hodgson, Frederick Thomas, 1836- · Chicago : F. J. Drake & Co. · leaf 139
e found to exactly intersectwith that of Fig. 4. Both mouldings here are shown as solid, and of thesame thickness. This is done for the purpose of mak-ing the drawing more plain and easily understood;but bear in mind that all crown mouldings are gener-ally sprung. To find the form of a sprung or… … PRACTICAL SOLUTIONS 137 when in a certain position, will instantly give theexact form of a rake moulding, and it will intersect,and mitre correctly with that of level moulding. Todo -this, take the level piece which has been mitred;lay its flat surface on the drawing; make its point Pat Fig. 5,…
Carpentry
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
