Modern carpentry and joinery : being a compilation of the very best things and most modern and practical methods known in the arts of carpentry and joinery (1910)
Hodgson, Frederick Thomas, 1836- · Chicago : F. J. Drake & Co. · leaf 144
^ Fig. 7. on the left. All the cuts being made, raise both sideson hinges A R and A 2; push the sections of mould-ings on right and left from you; make front edge rest PRACTICAL SOLUTIONS 141 on FD. Now bring mitres together, and we have apractical illustration of mitreing sprung mouldings onthe… … Fig. 8 shows the projection of a solid. This meansthe section of anything that is cut by a plane not paral-lel to its base; or, to put this in a more practical way—take a square bar of wood and cut it in the directionof BE; the section it makes is shown by BEFH;simple as this is, it still gives the…
Carpentry
