base of the semi-cone, and the triangle E C E its ver- 178 MODERN CARPENTRY tical section. From the apex C, with the length ofone of its sides as radius, described the arc E F, whichmake equal in length to the semi-circle E D E by step-ping lengths as previously described. Join F to C, andE C F is… … Fig. 43. centric arc IJ; then EIJE represents the coveringof the frustum. Any portion of this, the panels forinstance, is found in the same way. To draw the rails,divide their centre lines equall}^ on the perimeter, anddraw lines from the divisions to the centre as II C;make the edges parallel with…
