IM 196 MODERN CARPENTRY dow board is hinged to the front panelling or shutterback, so that when the former is lifted, the shutterscan pass down behind the back out of sight. Coverflaps hung to the outer linings on each side close overthe face of the pulley stiles and hide the cords. Whenit is… … Fig. 63. window board can then be lifted, and the shutters runup, a pair of flush rings being inserted in the top edgeof each for that purpose. The windoAv boardis nextshut down, the inside shutter brought down upon it,the outside one pushed tight up to the head, and themeeting rails, which overlap…
