hese points, every time the furnace 180 THE LOCOMOTIVE. [December, sheets moved relatively to each other, and in the course of time, after these bendingshad been repeated often enough, we should probablj^ find cracks started at both ends ofthe bolt. Even if the bending were not severe enough, in… … Fig. 3.—Suggesting why Stay-Bolts break only at the Outer Sheet. phices, so that the final result would be much the same as though the failure were due<liiectly to the bending strains. Thus far we have assumed that the two sheets are of equal thickness, and thatneither of them is thin enough to…
