occursthat the beam is subjected to the greatest stress, it fol-lows that it is of some importance to be able to deter- 346 MODERN CARPENTRY mine the bending moment of beams loaded under dif-ferent conditions. The bending moment—like othermoments—must always be expressed in terms of alength and a… … Fig. 57. The greatest tendency to bending will be at the pointof support, i. e. at a distance of 5 ft. from the load. .. Maximum bending moment=5X6=30 ft.-tons. Bending moment at 2 ft. from the wall (i. e. 3 ft.from the load) =3X6=18 ft.-tons. The bending moment at any distance from the loadmay be…
