The modern clock; a study of time keeping mechanism; its construction, regulation, and repair (1905)

Goodrich, Ward L · Chicago, Hazlitt & Walker · leaf 223

An illustration from The modern clock; a study of time keeping mechanism; its construction, regulation, and repair, 1905, leaf 223
are nar-row, the drop may appear to be sufficient. When the trainis put in action the depthing that is too great producesscratching or butting and the scape wheel trembles. Thisresults from the fact that the points of the teeth of thewheel touch the core of the pinion and cause it to buttagainst… … Fiir. CO nc

Clocks and watches
