The modern gas tractor, its construction, utility, operation and repair: a practical treatise defining every branch of up-to-date gas tractor engineering, driving and maintenance in a non-technical manner. Considers fully all types of power plants and their components, methods of drive and speed changing mechanisms. Describes design and construction as well as practical application of tractors in the field (1919)
Pagé, Victor Wilfred, 1885-1947 · New York : Scientific American Pub. Co. · leaf 455
the engine, showing itssimplicity and details of the fuel-feeding device is givenat Fig. 207. The arrangement of the water feed can 448 The Modern Gas Tractor be readily ascertained by reference to Fig. 208. Bothfuel and water feed may be regulated to secure propermixture proportions. Motor… … Fig. 209.—The Universal Motor Cultivator with One of the ^^lanyPossible Attachments that can be Used with It. just as well as to the cultivator attachment. The powerplant is a two-cylinder, V-type motor, of 3|-inch bore,and 5-inch stroke. The transmission is through wormgearing, housed in a…
