Modern locomotive engineering, with questions and answers .. (1913)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co · leaf 197
oints of cut-off, andthe indicator diagrams shown in Figs. 96 and 97 cer-tainly show an excellent steam distribution for allpoints of cut-off. The author desires to say in this connection that hehas seen the originals of these diagrams as taken fromengine 1026 of the C. & N. W. Ry. and can… … PISTON VALVES AND BALANCED VALVES 191 The Young valve and gear is an adaptation of theCorhss principle to suit requirements in locomotivepractice, and consists of two valves for each cylinder,operating alternately as inlet and outlet and driven bythe Corliss wrist motion, used in connection with…
Locomotives
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
