Cotton manufacture: a manual of practical instruction in the processes of opening, carding, combing, drawing, doubling, and spinning of cotton, and the methods of dyeing and preparing goods for the market (1894)

Lister, John, 1920- · London, C. Lockwood · leaf 59

An illustration from Cotton manufacture: a manual of practical instruction in the processes of opening, carding, combing, drawing, doubling, and spinning of cotton, and the methods of dyeing and preparing goods for the market, 1894, leaf 59
fast-and-loose-pulleys, giving motion to two spindle-driving shafts, B, theflyers being attached to the top of the spindles. In some arrange-ments, the bobbin leads the flyer, and in others the flyer leads thebobbin. The centre wheel, c, carries a pair of bevel-wheels, whichare put into gear by a… … 46 COTTON MANUFACTURE. way by the small pinion, k, and in the opposite direction to thebevel and spur wheels; the speed is in this way gradually increased,

Cotton manufacture

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
