Modern locomotive engineering, with questions and answers .. (1913)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co · leaf 252
mences,after which draw line R D, completing the parallelo-gram E T R D, fixing R as a point in the theoreticalcurve started at E. After drawing the diagonal T V,proceed in the same manner as before to locate theintermediate points. It will be observed that in order to ascertain the per-formance of… … Figure 114 cut-off and coincident with the actual curve, the testwill apply towards the end of the stroke. It is not tobe expected that the expansion curve of any diagramtaken in practice will conform strictly to the lines ofthe isothermal curve, especial/y towards the latter endof the stroke,…
Locomotives
