Modern locomotive engineering, with questions and answers .. (1913)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co · leaf 326
ri n ^ … 320 LOCOMOTIVE ENGINEERING ^^S- 153- A vertical section through the low-pressure cylinder saddle and intercepting valve, show-ing the intercepting and separate exhaust valves inthe position taken v/hen engine is working simple. Fig. 154. The same section as Fig. 153, but showsthe position of the…
Locomotives
